CS180 Project 1

Introduction

In this project, we are required to implement an image alignment algorithm that colorizing the glass plate images from Prokudin-Gorskii photo collection by aligning the three channels of each image.

Part 1: Simple implementation on smaller .jpg images

In this part, my implementation is simple: search over the displacement window of \([-15, 15]\) pixels to find the best displacement for red and green channels that minimize the errors with the blue channel. Below are my results, each with the displacements of red and green channels:

It is worth noticing that I tried calculating the errors with MSE (Mean Squared Error, \(\frac{1}{hw}\sum_{i=1}^h\sum_{j=1}^w (\mathbf{X}_{ij} - \mathbf{Y}_{ij})^2\)) and NCC (Normalized Cross-Correlation, \(\frac{\mathbf{x}^T\mathbf{y}}{\Vert\mathbf{x}\Vert_2\Vert\mathbf{y}\Vert_2}\)). While both of them turned out to work well in terms of visual effects, the runtime of NCC was larger than that of MSE, with a runtime of 1.11s on cathedral.jpg compared to 0.63s, so I used MSE for all of the images to enhance speed. Also, it is important to crop the image before processing it, as the black edges would influence error calculation and the aligning process would be less accurate. I cropped 5% of the height and 10% of the width of each image before processing.

Part 2: Coarse-to-fine pyramid speedup on large .tif images

Next, I applied the algorithms to the larger images. To reduce runtime, I downsampled each image at 4 levels, each averaging the pixels in 2x2 blocks. At level \(k\), the optimal shift \((i_k, j_k)\) is found within a search window \(([-windowH_k, windowH_k], [-windowW_k, windowW_k])\), then the shift \((i_{k+1}, j_{k+1})\) at the next level with a finer image is found within a search window \(([-windowH_{k+1} + 2i_{k+1}, windowH_{k+1} + 2i_{k+1}], [-windowW_{k+1} + 2j_{k+1}, windowW_{k+1} + 2j_{k+1}])\). The window sizes at each level (from coarse to fine) were set to [8, 6, 4, 2], [16, 8, 4, 2], and [18, 9, 6, 3]. Here are the results:

Extra self-selected images:

Part 3: Bells and whistles

During the implementation on emir.tif, it was not as easy as I expected, as the outcome image is still awful after a few refinements on my algorithm. Therefore, I decided to use the gradient calculated by Sobel operator as the alignment clue:

Meanwhile, the colors of some of the images were not as realistic as expected, being either too blueish or too yellowish. I attempted to adjust the white balance of the images by matching each channel's mean to that of an assigned channel:

Summary

This project is not very hard, as the way to build the algorithm is very clear. However, it is a rather interesting one, though I have already done some other image processing projects before. I believe the projects of this course would be more and more interesting later on.
